How are you? Install an internal PS5 SSD and expand your memory ? How every long-standing PlayStation 5 owners will tell you, the 825 GB SSD comes with which the console is delivered so far as you would imagine (see also: PS5-SSD: How much space has It? ). Since the operating system devours a little space, they will ultimately stay around 667 GB space for game installations that are quickly used up when they are an avid player with a large title library.

Fortunately, it is possible to use the storage capacity of your PS5 with a m.2-SSD . This means that you get the original 825 GB plus additional memory you add via a M.2 SSD.

In this PS5 instructions , we explain how to open your PS5 console for installation and how you can actually install your shiny new m.2-SSD and expand the available space for games with A PS5 SSD upgrade . If you have not bought a new drive yet, find the Best PS5-SSD: Compatible M.2-SSD memory expansion for PS5 over the link.

Note: The following steps only work when PS5 firmware is running 2.0-04.00.00 on your PS5. Do not try to install an SSD if you use the standard firmware for retailing, as this simply does not work.

PS5 SSD: To install an internal SSD and expand your store

In the following we will explain it How to install an internal PS5 SSD and show it so expand your memory .

Buy a compatible M.2-SSD

You might think that the PS5 would accept every old SSD, but they are wrong. You need a m.2-ssd and a heat sink must be connected. Sony recommends the SN850 from WD Black , which is provided with the personal quality seal of the PS5 system architect Mark Cerny. This is the model we used in this manual, and we can confirm that it works perfectly. Further options can be found in our Best PS5-SSD: Compatible M.2-SSD memory extension for PS5 manual.

You can use each M.2-SSD on your PS5 Extend your memory , but you need to make sure it is a reading speed from 5,500 MB / S or more and does not exceed a size of 110 x 25 x 11.25 millimeters with attached heat sink. You will find everything ps5 m.2 SSD extension requests over the link.

To repeat it again, regardless of which SSD model you use, make sure that a heat sink is installed - some are already pre-assembled, but you can buy heat sinks separately and attach to the SSD.

Read more: Best M.2-SSD for PS5 memory expansion

Open your PS5

First, make sure that you have disconnected your PS5 console from the power grid - never try to perform such installation when the device is switched on.

Turn the console so that the base of the device shows up, as shown below.

Image: Press Square

It does not look like it's an obvious way to remove the lower part of the PS5, but it's actually a very simple process if you know what you are doing. Grasp both sides of the white base plate as shown below.

Image: Press Square

Carefully lift the edge of the aperture with the right hand and then pull them to the side with the left hand in the direction shown. The panel should be released from the main body of the console on the right side and then peel off to expose the main body of the system.

Image: Press Square Image: Press Square

Remove the SSD slot cover

Right next to the PS5 fan, you will see a metal cover held by a single screw and on which the PlayStation icons are engraved. Love for detail, Sony! You can remove this screw with a commercially available Phillips screwdriver.

(Clockwise from top left) The SSD slot is located in the lower left corner of the console, as shown in this photo. Use a Phillips screwdriver to remove the screw and pay attention to the chic PlayStation icons. Lift the metal plate way to release the SSD slot below. (Pictures: Games Tips PS4)

Install your SSD

Once the slot is exposed, you can use your m.2-ssd . In this case we have the SN850 from WD Black .

Before installing the SSD, you must ensure that the heat sink is mounted. At the SN850, two rubber bands are included with which they attach the heat sink to the SSD itself.

(From left to right) the SN850 in his packaging. Beautiful or? The heat sink before it is mounted on the SSD itself. In the case of the SN850 there are two rubber bands that are used to connect the two together. Not just elegant, but hey, it works. (Pictures: Games Tips PS4)

As soon as SSD and heat sinks are combined, the next task is to actually integrate the SSD into your console. At one end of the SSD slot there is a screw and a spacer, which must be removed after installation of the SSD and to be installed again (but equal more). The size of the SSD, which you install, determines where the screw is located in the holes shown below.

Pictures: Games Tips PS4

Next, set the previously stored spacer (only the spacer, not the screw) in the screw hole under the SSD and then insert the SSD as shown in the slot. Make sure the contacts are properly aligned. Press it firmly and it locks, whereby only the screw (also stored earlier) can be attached up to keep it 100% safe.

(Clockwise from top left) Attach the spacer and then insert the SSD into the slot as shown. Make sure that the contacts of the SSD match the contacts in the slot. Press down to lock the SSD, bring the previously removed screw again and the installation is complete! (Pictures: Games Tips PS4)

Build the PS5 together again

Replace the SSD slot cover with the screw while the SSD is firmly seated and then restart the white base plate. You can do this by pushing it in the direction shown below until it clicks back.

Image: Press Square

Formatting the SSD for use in your PS5

If you turn on your PS5 after installing the SSD for the first time, see the following screen:

Image: Press Square

As you may expect, you must format the M.2-SSD To make sure the console can use it as a game memory. If you do not select this option at this time, the PS5 is started as usual and you can not use the intellectual additional space.

If you select the formatting option, see the following screen:

Image: Press Square

Installing an SSD into my childhood Original Xbox

You will then be communicated how quickly your SSD can read data, which affects the performance when games are installed on it. As you can see on the screen below, the SN850 is well above the read speed of 5,500 MB / s recommended by Sony, so we are all good.

Image: Press Square

After the operation has been completed successfully, see the following confirmation screen:

Image: Press Square

PS5 SSD: How to select the SSD as the primary installation location

By default, your PS5 plays games on your integrated SSD. So if you want to output games on your new M.2 SSD, you must change a setting. Go to Settings> Memory , and you see the following screen:

Image: Press Square

Here's information about available storage options on your PS5. You can also format the M.2-SSD from this screen from this screen if you have problems with it. What interests us, however, is the ability to select the M.2-SSD as the primary installation device. Navigate to installation location in the left menu. As you can see on the screen below, you have options for both PS4 and PS5 games.

Image: Press Square

PS5 SSD: How to move games to the M.2-SSD

If you want to change some of the games that you already installed on your PS5, you can do so with minimal effort. In the Settings> Memory Menu, select Console Storage and you get a list of all games and apps that are currently installed on the integrated SSD of your PS5.

Image: Press Square

Locate the item that you want to move to the M.2-SSD and select it. You see the following submenu:

Image: Press Square

The element is then moved to the M.2 SSD.

Pictures: Games Tips PS4

Have you an internal PS5 SSD installed and have expanded your store PS5 ? Take a look at our PS5 instructions , and let us know in the comment area below, how much space you have available. Remember, our list of Best PS5-SSDs over the link.
